Description
Portable design, easy to carry.
With 1080P HDMI Pass-through,you can playing HD game when you’re recording it. Easy to use, no any set-up. Click RECORD button to record video, and re-click to stop recording.
Connections
Interface USB 2.0 Host
Video Input Digital:HDMI
Audio Input Digital:HDMI
Video Output Digital:HDMI
Audio Output Digital:HDMI (Pass-through from HDMI or Audio RCA L/R Input)
Applicable Connections with Game Consoles
HDMI WiiU, Xbox 360,Xbox One,PS4, and other HDMI devices
Hardware Extra
Codec Hardware MPEG4 encoder
User Interface On-board Hot Button for one-click recording / streaming
LED indicator for working status
Dimensions: 110(L) × 75(W) × 27(H) mm
Weight: 135g
Standards
Storage Media USB Flash Disk, Portable Hard Disk
Note: The exFAT format is not supported.
Resolution Input/Pass-through: 1920 x 1080 (50i), 1920 x 1080 (60i),1920 x 1080 (24p), 1920 x 1080 (25p),1920 x 1080 (30p), 1920 x 1080 (50p),1920 x 1080 (60p)
Capture: 1920 x 1080 (50i), 1920 x 1080 (60i),1920 x 1080 (24p),1920 x 1080 (25p),1920 x 1080 (30p),1920 x 1080 (25p),1920 x 1080 (30p)
Note:Upscaling is not supported.
Record Format Video: AVI MPEG4,Audio:AAC Stereo
Record Quality Max:18Mbps@1080P 30fps
Record File Max:2GB / Per File
Record Place Max:140MB / Minute,8.4GB/ Hour
Power Supply DC 5V/2A
Capture Format Video:AVI MPEG4, Audio:AAC Stereo
Software Arcsoft Showbiz(Included):
Video Editing Timeline/Storyboard edit,Split/ Divide Scenes, Multi Trim Scenes …
Video Export Upload to YouTube
Portable Device:iPod,iPhone,iPod Touch,Apple TV,PSP, PS3, Xbox
File: MPEG 1/2/4,WMV HD,Quicktime(MOV) …
Operating System Windows 8 (32/64 bit),Windows 7 (32 / 64 bit),Windows Vista(32/64 bit)
CPU Intel Core 2 Duo 2.8GHz,AMD Athlon 64X2 Dual Core 3.0GHz
Memory 4 GB RAM
Graphics Card VGA card with support for DirectX 10.0c or above.
Package Contents
EZCAP285 x1
Power Supply x1
Software CD x1
Manual x1
Software CD x1
Manual x1
